Power Queen 12V 100Ah LiFePO4 Lithium Battery Deep Cycle BMS for Solar

RV

30-70lb Trolling Motor

Camping

Solar/Home Energy Storage

Off-grid

4 Charging Ways

Product Size: L13*W6.7*H8.4 IN. Match BCI Group 31 battery box. Power Queen 12V 100Ah LiFePO4 Battery is an energy storage battery rather than a start-up battery, we do not advise using the Power Queen 12V 100Ah Battery as a starting battery or to power any golf carts.

【Half Lightweight And Twice Capacity】Power Queen 12.8V 100Ah LiFePO4 battery weighs only 24.25 lbs, only half weight and providing twice capacity in the same size as lead-acid batteries, you can easy to move and install. And our LiFePO4 battery is 100% usable capacity compared with lead-acid battery only provide 60%~70% capacity, which can be tested by a percent state of charge meter.

【Extendible Storage For Various Scenarios】Power Queen 12.8V 100Ah LiFePO4 batteries support up to 4 in series or 4 in parallel (Max 4S or 4P) to get more capacity (100Ah , 200Ah, 300Ah, Max.400Ah) and higher voltage (12.8V, 25.6V, 38.4V, Max.51.2V). Our customer usually connected it in parallel/series and used on camper RV, solar home system, trolling motor.

【BUILT-IN 100A BMS & 5-Hour Fast Charging】Our 12.8V 100Ah Lithium battery builds in 100A BMS, which can prevent the LifePO4 battery from the most common issue causing of battery failure, such as overcharge, over-discharge, over-current and short circuit. Our 12.8V 100Ah LiFePO4 battery only needs a 5-hour fast charging time when charging by 14.6V 20A LiFePO4 battery charger, saving 50% time in charging compared with lead-acid battery which needs 10 hours charging time to around 70% capacity.

【Eco-Friendly Energy & Save 1/2 Power Fees】Power Queen 12.8V 100Ah LiFePO4 battery provides up to 15000+ cycles times and 1280Wh energy, which means our 100Ah battery produces more energy in its 10-year lifespan, which means you will save 1/2 of power fees compare with using the utility power. Our LiFePO4 batteries are widely used for solar system, RV trip and outdoors activities, you could enjoy self-reliant colorful life when using the battery in solar source.

【Warm Tips】① This Battery is an energy storage battery rather than a start-up battery, we do not advise using it to start engines or golf carts. ② If OT terminals are attached directly with screws and their thickness is less than 2mm, please add gaskets to ensure secure attachment and prevent loosening or overheating. The same precaution applies when using clamps

SPECIFICATION

Nominal Voltage: 12.8V

Amp Hours :100 Ah

BMS: 100A

Battery Max. Load Power: 1280 W

Battery Energy :1280Wh

Max. Continuous Charge/Discharge Current :100A

Size:L13 x W6.77 x H8.43 inch

Application: Solar, RV, Camper, Off-grid,Trolling Motor (30~70lb thrust)

PACKAGE INCLUDED

12V 100Ah LiFePO4 Battery *1

Product Manual *1

Please be noted: battery charger is not included.

Q&A

Q1: What is the warranty for your batteries？

A: We provide a 5-year warranty for our Power Queen battery and lifetime after-sales service.

Q2: Does the BMS has built-in low temperatures cut off?

A: For Power Queen 12V100Ah Basic LiFePO4 battery doesn't have a low temp cut-off. Pls check the 100Ah Low Temp Protection model if you want this function.

Q3: What is the heighth of the 100Ah battery?

A: The height of the 100Ah battery is 8.43 inches.

Q4: Each battery holds about 1kw correct?

A: Yes, each Power Queen 12V100Ah LiFePO4 battery holds 1280Wh of energy.

Q5: can you charge and discharge this battery at the same time?

A: Yes, with a solar system, you can charge and discharge the battery at the same time.

Q6: Can this battery be mounted on its side?

A: For the Power Queen 12V100Ah LiFePO4 battery we would recommend mounting it upright with terminals facing up.
